描述
 |
 |
 |
 |
| Digital Speedmeter | 4WD Drive System | Advanced Shaft drive | Electric winch & Tow ball equipment |
| ENGINE | |
| Engine Type: | 350cc-Liquid cooled, 4-stroke, CVT with Balance Shaft |
| Start: | Electric |
| Ignition: | C.D.I |
| Transmission: |
Shaft Drive & CVT & H-L-N-R Button 4WD |
| Max Power: |
15.2kw @ 7100 RPM |
| Max Torque : | 28nm @ 5700 RPM |
| Borex Stroke: | 78mm x 65mm |
| Fuel : | EFI system & 92# Unleaded Petrol |
| Fuel Capacity: | 14 L |
| CHASSIS | |
| Suspension/Front: | Double Wishbone |
| Suspension/Rear: | Single Wishbone |
| Brakes/Front: | Hydraulic Disc Brake |
| Brakes/Rear: | Hydraulic Disc Brake |
| Tires/Front: | AT 25×8-12" |
| Tires/Rear: | AT 25×10-12" |
| DIMENSIONS | |
| Overall Size-L*W*H: | 2035*1250*1200 mm |
| Packing Size-L*W*H: | 2140*1290*870 mm |
| Seat Height: | 930 mm |
| Ground Clearance: | 300 mm |
| N.Weight: | 300 kgs |
| Max. Load: | 200 kgs |
| OTHERS | |
| Max. Speed: | 75km/h+(Depends on the Ground and Terrain situation) |
| 40HQ: | 27 PCS |
· All figures based on the latest information and subject to change without notice and obligation.
